TIGER G2
Tiger 433 MHz products are the first choice for companies looking for the most advanced remote control solutions. One transmitter can control up to 15 receivers. With its robust constructions, both transmitter and receiver are protected against moisture and dust with a minimum of IP65. Lithium battery in all cases, internal rechargeable or rechargeable and interchangeable depending on the model.
 |
 |
 |
 |
 |
 |
|
| Product code | T9-1 | T9-2 | T11-4 | T11-5 | T14 | T15 |
| Buttons | 8 | 6 | 10 | 12 | 6 analog | 4 x 2 - steps | 8 analog | 4 x 2 - steps |
| Screen | no | LCD | LCD | no | LCD | LCD |
| Frequency | 433 MHz 69 channels | 433 MHz 69 channels | 433 MHz 69 channels | 433 MHz 69 channels | 433 MHz 69 channels | 433 MHz 69 channels |
| Batteries | Li-ion rechargeable | Li-ion rechargeable | Li-ion rechargeable and interchangeable | Li-ion rechargeable and interchangeable | Li-ion rechargeable | Li-ion rechargeable |
| Protection | IP66 | IP66 | IP65 | IP65 | P66 | P66 |
| Certifications | CE | CE | CE | CE | CE | CE |
| Temperature | -20°C to 55°C | -20°C to 55°C | -20°C to 55°C | -20°C to 55°C | -20°C to 55°C | -20°C to 55°C |
| Security level | SIL3, PLe | SIL3, PLe | SIL3, PLe | SIL3, PLe | SIL3, PLe | SIL3, PLe |
| Dimension | w76 x h160 x d37 mm | w76 x h160 x d37 mm | w76 x h210 x d37 mm | w76 x h210 x d37 mm | w79 x h220 x d56 mm | w79 x h245 x d56 mm |
| Datasheets | T9-1 datasheet | T9-2 datasheet | T11-4 datasheet | T11-5 datasheet | T14 datasheet | T15 datasheet |
| Name | R4 | R9 | R10 |
| Frequency | 433 MHz 69 channels | 433 MHz 69 channels | 433 MHz 69 channels |
| Relays | 7 (R4-01), 17 (R4-06), 11 (R4-36), 7 (R4-26), 7(R4-41) | 12 (R9-1, R9-6) 28 (R9-11) | 7 |
| Weight | 800gr (R4-01, R4-26), 950gr (R4-06) | 1800gr | 650gr |
| Antenna | 1 BNC connector for external antenna | 2 BNC or 2RP-SMA connector for external antenna | 10 pin connector, internal antenna |
| Protection | IP66 | IP66 | IP65 |
| Dimensions | w176 x h160 x d75 mm (R4-01, R4-06), w176 x h126 x d52 mm (R4-36, R4-26, R4-41) | w256 x h175 x d85 mm | w152 x h139 x d58 |
| Temperature | -20 °C to 55°C | -20 °C to 55°C | -20 °C to 55°C |
| Certification | CE | CE | CE |
| Datasheets | R4-01, R4-03, R4-06, R4-08, R4-26, R4-28, R4-36, R4-38, R4-41 & R4-43 | R9-01, R9-02, R9-06, R9-07, R9-11 & R9-12 | R10-01 & R10-02 |
